Vacuum Contactor HVJ30 1.14kv 1250A AC for switchgear from JUCRO Electric

Vacuum Contactor HVJ30 1.14kv 1250A AC for switchgear from JUCRO Electric

Vacuum Contactor HVJ30 1.14kv 1250A AC for switchgear from JUCRO Electric
Vacuum Contactor HVJ30 1.14kv 1250A AC for switchgear from JUCRO ElectricVacuum Contactor HVJ30 1.14kv 1250A AC for switchgear from JUCRO ElectricVacuum Contactor HVJ30 1.14kv 1250A AC for switchgear from JUCRO Electric
CategoriesVacuum Contactor
BrandJUCRO
ModelHVJ30-1.14/1250
Unit PriceUS $ 406-408.4 / piece
FOB portshanghai/ningbo
Terms of PaymentL/C, Western Union, MoneyGram, T/T
Update TimeDec 11,2024
Detail Information

 Vacuum Contactor HVJ30 1.14kv 1250A AC for switchgear from JUCRO Electric

Vacuum Contactor accept customized order according to technical drawing or samples.

HVJ30 1.14kv vacuum contactor 1250A

The HVJ30-1.14 / 1250 series AC vacuum contactor is applicable for the 50 HZ AC power system with nominal voltage 1.14KV and rated current up to 1000A ~ 1250A to open and close the circuit, start and control the AC motor frequently. It is suitable for composite magnetic starters with several protection devices (integrated JDB electronic protector, type of JR9 overcurrent protection, resistance and capacitance absorbents). It is especially suitable for composing an explosion-proof magnetic starter and a large-size mineral switch.

Items
Unit
HVJ30 1.14/1250
Main circuit rate voltage
(kV)
1.14
Main circuit rate current
(A)
1250
Main circuit making ability
(A)
5000(100 times)
Main circuit break-make ability
(A)
4500(10 times)
Maximum breaking ability
(A)
5000(3 times)
Electrical life AC3
(times)
600,000
Electrical life AC4
(times)
100,000
Mechanical life
(times)
1,000,000
Rated operating frequency AC3
(times /h)
600
Rated operating frequency AC4
(times /h)
120
Short-time operating frequency
(times /h)
1000
Contacts separation
mm
2.8±0.1
Over travel
mm
1.0±0.1
Packing & Delivery

Strong package, Safety first.

Inside with foam to support the product, put it in carton or wooden box, fixed it on pallet.

As long as possible to keep the products safe until it arriving customer's warehouse.

Clearly marking label outside of package, customers will be easy to identify their goods.
Our Company
20000 M2 of JUCRO Electric company land
1500 M2 of office building
5000 M2 of workshop building
Inside of JUCRO Electric office building
Inside of JUCRO Electric office building
JUCRO Electric office work area
Workshop

Vacuum Interrupter Workshop

Accept customized order.
Design the Vacuum Interrupter for you.

VCB Production Line

VCB Vacuum Circuit Breaker production Line.

VCB Vacuum Circuit Breaker production Line.

VCB Vacuum Circuit Breaker production line, Engineers routine inspection.
Quality Inspection
 Carefully inspection of each product, Quality guaranteed
 completely data records of entire process , all the product data can be traced.
