Vacuum Contactor HVJ20 2KV High Voltage AC  for switchgear from JUCRO Electric

Vacuum Contactor accept customized order according to technical drawing or samples.

HVJ20 series vacuum contactor has higher rated current, smaller size and anti-dusty advantages. It can be used in AC50 ~ 60Hz, 2KV power system, rated current to 800A, for long distance making-breaking and frequent starting and controlling of AC motor.

Rated voltage: 2 kv

Rated current: 630A

c)Humidity:

-Relative humidity: daily mean not higher than 95℃,monthly mean not higher than 90℃;

-Aqueous vapor pressure: daily mean not exceed 2.2 KP, monthly mean not exceed 1.8 KP

Ambient air should not be obviously polluted by corrosive or flammable gas or vapor;

C)Free of frequent severe vibration; When running, angle of inclination between installation surface and horizontal plane should not exceed 5℃

Items
Unit
HVJ20-630
Main circuit rate voltage
(kV)
2
Main circuit rate current
(A)
630
Main circuit making ability
(A/100 times)
6300
Main circuit break-make ability
(A/10 times)
5000
Maximum breaking ability
(A/3 times)
6300
Electrical life AC3
(times)
600,000
Electrical life AC4
(times)
100,000
Mechanical life
(times)
1,000,000
Rated operating frequency AC3
(times /h)
300
Rated operating frequency AC4
(times /h)
120
Short-time operating frequency
times /h(20S)
1200
Clearance between open contacts
mm
3±0.3
Packing & Delivery

Strong package, Safety first.

Inside with foam to support the product, put it in carton or wooden box, fixed it on pallet.

As long as possible to keep the products safe until it arriving customer's warehouse.

Clearly marking label outside of package, customers will be easy to identify their goods.
Our Company
20000 M2 of JUCRO Electric company land
1500 M2 of office building
5000 M2 of workshop building
Inside of JUCRO Electric office building
Inside of JUCRO Electric office building
JUCRO Electric office work area
Workshop

Vacuum Interrupter Workshop

Accept customized order.
Design the Vacuum Interrupter for you.

VCB Production Line

VCB Vacuum Circuit Breaker production Line.

VCB Vacuum Circuit Breaker production Line.

VCB Vacuum Circuit Breaker production line, Engineers routine inspection.
Quality Inspection
 Carefully inspection of each product, Quality guaranteed
 completely data records of entire process , all the product data can be traced.
